| ब्रांड नाम: | DONJOY |
| मॉडल संख्या: | NO.1107008 |
| न्यूनतम आदेश मात्रा: | Negotiation |
| कीमत: | US $150 - 1,200 / Piece |
| पैकेजिंग विवरण: | carton box |
| भुगतान की शर्तें: | T/T, LC, Credit Card |
304 / 316L sanitary manual regulating reversing seat valve DN25 - DN150
Tag
donjoy sanitary reversing valve
Manual Flow control Valve
DONJOY Seat Valve
Specification
|
Product Name |
Sanitary manual reversing Seat valve,SMS,DIN,INCH.. |
|
Valve body material |
SS304 or SS316L |
|
Seal material |
EPDM / FPM / VITON |
|
Max.working pressure |
10 bar |
|
Max.working temperature |
130°C |
|
Size |
DN25 - DN100 or 1" - 4" |
|
Connection |
Threaded, welded, clamped,Flange |
|
Standard |
DIN, SMS, RJT, 3A |
|
Operating mode |
Manual, Pneumatic,IL Tope, Positioner |
|
Certificate |
FDA, CE, ISO,3A |
|
|
Reversing valve, rotary handle, position safety lock, |
|
Adjust |
360° adjustable body |
|
Hygienic Design |
According to 3A Standard |
|
Assembly |
Easy assembly, disassembly of internal parts by loosening a clamp fastener |
|
manual operation |
By fine tuning handwheel |
Operating Principles
Seat valve are operated automatically by a single-acting or a double-acting pneumatic actuator. By supplying compressed air, the shaft is moved to place the valve in the "open" or "closed" position.
Feature
The material connected with others: AISI 316L / 1.4404
The material in other part: AISI 304
Seal ring: EPDM FDA 177.2600
Inernal surface finish: Ra ≤ 0.8μm
External surface finish: CNC fine machining
Options
Gasket: NBR / MVQ / FPM
Pneumatic actuator of double acting
Inductive position sensor
C - TOP control head
Position sensor
Connection type: SMS, RJT, DIN, 3A, ISO, Clamped, welded and threaded etc.
Product drawings
